PGCS 2

Portable Ground Control Station for UAV

Overview

The Portable Ground Control Station 2 (PGCS 2) is a secure computer with pre installed software intended to monitor and control the unmanned vehicles and to display the video feed from the platform in real time. In addition to the standard keyboard, PGCS is equipped with joysticks to control the platform and the payload. It is designed for simultaneous operation by the aircraft and the payload operators..

Command module of unmanned aerial system is designed to accommodate:

  • Equipment for communication and control
  • Unmanned aerial system operator and payload operator
  • Equipment for technical support of unmanned aerial system
  • Antenna telemetry and control – directional antenna
  • Antenna video and data – directional antenna
  • Iridium satellite modem (optional)

PGCS 2 provides:

  • Real-time telemetry information from the UAV/platform
  • Payload control
  • Reception, recording, storage and playback of payload information with real time display
  • Control of flight modes and payload operation
  • Preparation and upload of the mission
  • Real-time platform health monitoring
  • Preflight and post-flight inspection
  • Registering target coordinates
  • Flight mission control
  • Flight mission protocol logging
  • Flight mission simulation

Specifications

  • -30°C..50°C
  • Length 445 mm, width 344 mm, height 128 mm
  • Not less than 2.5 hours
  • Not exceeding 12 kg
  • - Secure keyboard
    - 18 function buttons, 3 rotary controls, 4 switches
    - Payload joystick
    - UAV joystick
    - Accelerator joystick
    - Battery status indicator
  • - Standard internal Li-Fe rechargeable battery: 19.8 V x 20 A/h
    - External power supply/charger : 22...27V x 8A
  • Intel i7-4600U (HASWELL) 64-bit dual core 2.1GHz (turbo boost up to 3.3GHz)
  • Mobile Intel 8 Series (Lynx Point) in MCP package
  • 8 Gb
  • 15" 1024 x 768, 1100 cd/m2
  • SSD 120 GB
  • Realtek ALC888-VC2 HD audio codec
  • - WLAN 802.11ac (2.4/5GHz dual band Intel 7260HMW)
    - Bluetooth 4.0
  • - 1 x USB 3.0
    - 1 x RJ45
    - Amphenol PT02E18-32P
  • - 2 x RS232
    - 1 x USB 3.0
    - 1 x GbE LAN
